The Analog Discovery 2 comes packaged in a durable project box that will fit all the included accessories and some additional adapter boards. The Analog Discovery can be connected to circuits and designs via the included female flywires, or used in conjunction with the included gender changers when a male connection is necessary.Īccessories can be purchased separately to provide additional functionality, such as the BNC Adapter for higher bandwidth and BNC connectors, or the Breadboard Adapter and Breadboard Breakout for a direct connection to the breadboard, or the Impedance Analyzer for additional Impedance measurement functionality. It's durable enclosure measures ( 3.23 inch x 3.25 inch x7/8 inch) and fits in a pocket. The Analog Discovery 2 is designed to be a portable alternative to a stack of benchtop equipment.
The analog and digital inputs and outputs can be connected to a circuit using simple wire probes alternatively, the Analog Discovery BNC Adapter and BNC probes can be used to connect and utilize the inputs and outputs.ĭriven by the free WaveForms software (Mac, Linux, and Windows compatible), Analog Discovery 2 can be configured to work as any one of several traditional test and measurement instruments including an Oscilloscope, Waveform Generator, Power Supply, Voltmeter, Data Logger, Logic Analyzer, Pattern Generator, Static I/O, Spectrum Analyzer, Network Analyzer, Impedance Analyzer, Protocol Analyzer, and Curve Tracer. Developed in conjunction with Analog Devices and supported by Xilinx University Program, this test and measurement device is small enough to fit in your pocket, but powerful enough to replace a stack of lab equipment, providing engineering professionals, students, hobbyists, and electronic enthusiasts the freedom to work with analog and digital circuits in virtually any environment, in or out of the lab. Interested in purchasing the Analog Discovery 2 along with accessories? Check out our Pro Bundle, Ultimate Bundle, Student Bundle! What is the Analog Discovery 2?ĭigilent Analog Discovery 2 is a USB oscilloscope, logic analyzer, and multi-function instrument that allows users to measure, visualize, generate, record, and control mixed-signal circuits of all kinds.
